When you use VVDI Key Tool Plus to calculate password for BENZ vehicle, you need use token for calculate. You can buy 1 Token for Xhorse VVDI Key Tool Plus Pad Benz BGA Password Calculation
1 Token for VVDI Key Tool Plus Mercedes Password Calculation
1. Compatible with VVDI Key Tool Plus to Calculate Password for Mercedes Benz Vehicle
2. No Need Shipping,
Just Provide Key Tool Plus Device Serial Number After Payment
3. After Finish Payment, Please Send Your Device Serial Number With VK08**** So That We Can Activate Token In Time
4. If Your Key Tool Plus with Other Serial Number (Not Start with VK08****), Please Buy the Tokens With Another Link (XNR-SS240) for your Device
5. When You Use VVDI Key Tool Plus Pad to Calculate Password for BENZ Vehicle, You Need Use Tokens.
For customer with Condor machine, factory provide one day one time service for free, for customer do not have Condor machine, must buy this tokens. You
can add this token into your machine, so you can calculate at any time.
Password Calculation -- Working Key -- Can Get the Key Password From Working Key and EIS (Online)
1). CAN protocol EIS all support password calculation (support BGA keys and other NEC keys)
2). We also support calculate password for NEC v51, v57 keys. No soldering.
3). Data acquisition time depends on the key version. It needs about 3.5 minutes -13 minutes, BGA version need about 5 minutes
4). Calculate time in server: 30 seconds – 1 minute
5). Key Tool Plus Pad is the fastest tool for password calculation
6). Lost all key password calculation: Now we support calculate password for W166, W212, W246, W212(old, with ELV), W204, W207
1. Support Type (Have Working Key)
W166, 197, 212, 218, 246
W169, 209, 211
W172, 204, 207
2. Password Calculation – Lost All Key:
1) Support W166, W212, W246, W212(old with ELV), W204, W207 EIS for password calculation while lost all working key
2) Lost All Key Data Acquisition time depends on EIS type, It needs about 3.5-8 minutes
3) Lost All Key Calculate time in server: 30 seconds – 1 minute
4) Support Type (Lost All Key Support Type)
W166, 197, 212, 218, 246
W212 (old with ELV)
How to Check Key Tool Plus Paid Token?
Please Check in IMMO Programming/ Benz. If add OK,it will display number for paid calcuation.
Mode: OBD and IR adaptor, mode use for communicate with EIS
Chassis: Select chassis number, you can detect it with auto detect in EIS Tools
Data Acquisition: Press "Data Acquisition", it will continue with following steps automatically
1) Insert working key to ignition, waiting 15 seconds
2) Insert working key to device IR reader, verify key and car
3) Data acquisition
4) Insert working key to ignition, waiting 30 seconds
5) Insert working key to device IR reader, wait end...
6) Save acquisition data
Upload Data: Upload saved acquisition data to server for calculate password.
Attention: Once success calculate password for one SSID, the server will not accept calculate the acquisition data with same SSID in 2 hours. After 2 hours, acquisition data with same SSID upload to server will start with a new task
Query result: Query server calculation result. The password will fill in key password area automatically after success calculation. Use "Copy" copy password to clipboard
Auto reflash: Program will auto re-flash server result until there's no task for this device.You can start data acquisition once more while auto reflash starting
Stop acquisite after success: If you are run data acquisition while auto reflash running,program will stop the acquisition progress when find correct password
About Query Result Status
Query result support query calculation result in 24 hours, others don't support Query result will display Time, SSID, Status, Filename (name when upload to server)
Status has the following types:
1) Queuing: number x, require about y minutes, means your task need y minutes
2) Processing: requires 1 minutes, means your task need 1 minute to finish
3) Password: xxxxxxxxxxxxxxxx (Free), means success find password, "Free" show this task is calculated for free or this task already success calculated before
4) Discard: Once you success calculate the password, in 2 hours, the upload acquisition data with same SSID will discard
5) Already upload: means the server already have this file in queuing
6) Pay for password calculation before upload: means your device doesn't have authorize for calculation. Contact your dealer and pay for password calculation
7) Failed: means this task failed to get password, you can run data acquisition again.Failed task is always free
